Tungsten Carbide Nozzles

Retop manufactures precision tungsten carbide nozzles engineered for long wear life, chemical resistance, and performance in abrasive blasting, slurry flow, and high-velocity spraying systems.

Mô tả sản phẩm

Tungsten carbide nozzles are high-performance components used for directing high-speed media—liquid, gas, or abrasive particles—through controlled orifices. Manufactured from sintered WC-Co alloys, these nozzles deliver exceptional hardness (HRA ≥ 90), superior erosion resistance, and precise flow geometry. Retop produces standard and custom-shaped nozzles including straight bore, venturi, conical, and multi-hole types, with various thread configurations (NPT, BSPT, Metric) for easy system integration.

Carbide nozzles are widely used in abrasive blasting machines, mining slurry systems, oilfield mud spraying, concrete pumping, fertilizer injection, high-pressure washers, and descaling operations. Their robust performance in corrosive, particle-heavy, or high-velocity applications makes them essential for industries such as mining, petroleum, shipbuilding, foundry, tunnel boring, and cement processing.

Đặc trưng

High Hardness & Erosion Resistance
Rated HRA 88–92, outperforms steel and ceramic nozzles in lifespan and reliability.
Stable Flow and Spray Patterns
CNC-machined inner geometries ensure uniform media distribution and directional accuracy.
Threaded and Press-Fit Options
Compatible with multiple installation styles (screw-on, clamp-on, weld-in).
Corrosion Resistant Grades Available
WC-Ni or WC-CoCr versions for exposure to acidic or salt-rich environments.
Wide Size and Orifice Range
Inner diameters from 0.5 mm to 30 mm, custom channel profiles available.

Thông số kỹ thuật

Đặc điểm kỹ thuật	Giá trị
Vật liệu	Tungsten Carbide (WC+Co / WC+Ni)
Độ cứng (HRA)	88 – 92
Orifice Diameter	0.5 mm – 30 mm
Types	Straight, Conical, Venturi, Custom
Mounting	NPT, BSPT, Metric, Press-fit
Ứng dụng	Abrasive blasting, Slurry jets, Mud spraying, Concrete pumping

Tại sao nên chọn Retop làm nhà cung cấp của bạn?

Retop has over 14 years of experience manufacturing wear-resistant tungsten carbide components for global customers in mining, oilfield, and industrial equipment sectors. Our carbide nozzles are produced with high-purity powders, HIP sintering, and precision CNC machining to ensure optimal flow control, tight tolerances, and consistent performance. We offer both standard sizes and full customization based on your drawings, with reliable delivery and technical support for every order.
